Cerwin-Vega
XED4004D XED Series 4-Channel Full Range Class-D Amplifier
Part # XED4004D
Coming soon
XED Series 4-Channel Full Range Class-D Amplifier. Made for car audio setups.
Get notified when it is available
We will email you once when this item is in stock.
Delivery across Canada
We will ship to every province and territory.
Returns
Full return terms will be posted at launch. See delivery & returns.
Manufacturer warranty
Brand-new, genuine product covered by the manufacturer warranty.
Specifications
- Brand
- Cerwin-Vega
- FREQUENCY RESPONSE (HZ)
- 35HZ - 350HZ
- RMS POWER PER CHANNEL 4Ω
- 60W x 4
- RMS POWER PER CHANNEL 2Ω
- 90W x 4
- Power Supply
- Full WPM
- Power Supply Threshold
- 10.0V-16.0V (DC)
- Idle Current
- (0.7A)
- THD 4 (1KHZ @4Ω)
- 0.1%
- S/N RATIO (A WEIGHTED @1W)
- -85dBA
- S/N RATIO (A WEIGHTED @FP)
- -101.1dBA
- Low Level Input
- 250mV-10.0V
- High Level Input
- 1.3V~>20.0V
- Output Impedance
- 2Ω
- Damping Factor (50Hz@4Ω)
- >70
- Bandwidth (-3db)
- 10Hz-30KHz
