Mono Mono Amplifier
Coming soon
Mono Mono Amplifier. Made for car audio setups. At a glance: 1 channels.
Get notified when it is available
We will email you once when this item is in stock.
Delivery across Canada
We will ship to every province and territory.
Returns
Full return terms will be posted at launch. See delivery & returns.
Manufacturer warranty
Brand-new, genuine product covered by the manufacturer warranty.
Specifications
- Brand
- Audison
- Channels
- 1
- Class
- A-Class
- Hi Level Input
- No
- Low Level Input
- Yes
- Digital Input
- Yes
- Power supply voltage / fuse
- 11 ÷ 15 VDC
- Operating power supply voltage
- 11 ÷ 15 VDC
- Idling current when off
- 0.04 mA
- Consumption @ 14.4 VDC, 1Ω, Max Musical Power
- 132 A
- Remote OUT
- 12 VDC (20 mA)
- Remote IN
- 7 ÷ 15 VDC (1 mA)
- Distortion - THD @ 100 Hz, 4Ω, 70% Rated Power
- 0.01 %
- Bandwidth A
- (-3 dB, 2 VRMS, 4 Ω): 5 ÷ 40k Hz
- S/N ratio A
- (A weighed @1 V): 106 dBA
